T-780E 780e T780E THERMO KING refrigeration unit electric fan with diesel engine with electric standby made in China
Product Description
The Thermo King T-780E is a self-powered truck refrigeration unit in the T-80E Series, developed for reliable temperature-controlled distribution with stronger capacity, quick pull-down, lower fuel consumption and easy service access. It uses a GreenTech low-emission engine, X214 compressor, electric evaporator fan, and TSR controller for stable load protection and efficient daily operation. The T-780E delivers 8,150 W cooling at 0°C and 4,100 W at -20°C on engine power, with electric stand-by capacity of 6,300 W at 0°C and 3,250 W at -20°C, making it suitable for both chilled and frozen transport applications.
| Product type |
Self-powered truck refrigeration unit, T-80E Series |
| Model No |
T-780E |
| Condition |
New |
| Original country |
China |
| Cooling capacity on engine power |
8,150 W at 0°C / 4,100 W at -20°C |
| Cooling capacity on electric stand-by |
6,300 W at 0°C / 3,250 W at -20°C |
| Heating capacity |
3,100 W |
| Heating capacity with water-heating option |
6,300 W |
| Airflow volume @ 0 Pa static pressure |
3,000 m3/h |
| Engine |
TK 370, low-emission, 3-cylinder, liquid-cooled |
| Engine rating |
11.2 kW |
| Maintenance interval |
2,000 hr |
| Compressor |
X214, lightweight aluminium alloy |
| Compressor displacement |
228 cc |
| Electric stand-by option |
380V / 3Ph / 50Hz and 230V / 3Ph / 60Hz |
| Electric stand-by motor rating |
4.5 kW |
| Refrigerant |
R-404A |
| Refrigerant charge |
3.5 kg |
| Dimensions |
1888 * 919 * 618 mm |
| Weight, Model 30 |
432 kg |
| Weight, Model 50 |
457 kg |
| Controller |
TSR controller |
| Key controller / operation features |
Symbol display, programmable service intervals, maintenance reminders, oil and coolant alerts, USB communication, PC Monitor diagnostics |
| Fuel-saving features |
Cycle-Sentry mode, Fuel Saver Mode, claimed up to 15% less fuel consumption |
| Standard / notable features |
EMI 2000, TherMax system, high speed lock out, pre-trip check, TSR in-cab HMI, diesel/electric auto switching, auto phase correction |
| Optional features |
Whisper low-noise kit, water-heating, multiple temperature control option |
| Construction / design highlights |
Electric evaporator fan, removable side doors, aerodynamic skins, recyclable Geloy plastic panels |
| Parameter |
| model NO. |
|
T-780E |
T-880E |
T-1080E |
T-1280E |
| Cooling Capacity (ATP International Standard, Ambient Temperature: 30℃) |
| Engine-driven (W) |
0℃ |
7,100 |
8,150 |
10,200 |
11,300 |
| -20℃ |
3,700 |
4,100 |
5,500 |
7,300 |
| Standby Power Drive (W) |
0℃ |
6,100 |
6,300 |
6,600 |
7,200 |
| -20℃ |
3,000 |
3,250 |
4,400 |
5,400 |
| Heating Capacity (Corps Temperature 2℃, Ambient Temperature -18℃) |
| Engine-driven |
|
3,100 |
3,100 |
4,100 |
4.100 |
| Engine-driven + Water Heating (Optional) |
|
6,300 |
6,300 |
7300 |
Z300 |
| Air Volume |
| At zero static pressure (m³/h) |
|
2,300 |
3,000 |
3,300 |
3,300 |
| Weight (kg, approx.) |
| Model 30 (Basic Model) |
|
426 |
432 |
454 |
457 |
| Model 50 (Basic Version + electric standby) |
|
451 |
457 |
502 |
514 |
| Engine (Low Emission, Three-Cylinder, Liquid-Cooled) |
| Model |
|
TK 370 |
TK370 |
TK 376 |
TK 376 |
| Engine Power (kW) |
|
11.2 |
11.2 |
14.6 |
14.6 |
| Maintenance Interval (h) |
|
2,000 |
2,000 |
2,000 |
2,000 |
| Compressor (High-strength Lightweight Aluminum Alloy) |
| Model No. |
|
X214 |
X214 |
X426 |
X430P |
| Displacement (cm³) |
|
228 |
228 |
424 |
492 |
| Electric standby |
| Voltage/Phase/Frequency (V/Ph/Hz) |
|
380V/3Ph/50Hz, 230V/3Ph/60Hz |
| Nominal Power (kW) |
|
4.5 |
4.5 |
75 |
7.5 |
| Refrigerant (R404A, Environmentally Friendly) |
| Charging Quantity (kg, approx.) |
|
3.4 |
3.5 |
3.5 |
3.6 |
