Product Details:
|
| Usage: | Medium Refrigerated Transportation | Optional: | Standby Electric/heating |
|---|---|---|---|
| Color: | White | Brand: | Thermoking |
| Application: | Transport Freezer | Refrigeration Unit: | Thermo King Option |
| Material: | Aluminium Coil | ||
| High Light: | 2.5kg Roof Mounted Refrigeration Unit,24 VDC Roof Mounted Refrigeration Unit,2.5kg 6 Cylinder Refrigeration Unit |
||
RV series:
RV, the abbreviation for fast cooling / reliable / rotary vehicle drive, is specially designed for light transport refrigeration
And medium delivery vehicles.
The new RV platform is equipped with optimized refrigeration system, rugged TK compressor and other proven components to ensure
High cooling capacity, fast pull-down, precise temperature control, high reliability, easy to use and low maintenance cost.
| Model RV-200 RV-300 RV-380 RV-580 | ||||||
| Temp. Range | -25℃~+30℃ | |||||
| Refrigerant | R-404A | |||||
| Charge (kg) |
1.10 (TK08 compressor) |
1.15 (TK15 compressor) |
1.2 | 1.8 | 2.5 | |
| Compressor | ||||||
| Model | TK08 | TK15 | TK15 | TK16 | TK16 | |
| Number of Cylinder | 6 | 6 | 6 | 6 | 6 | |
| Displacement (cm3) | 82 | 146 | 146 | 163 | 163 | |
| Cooling Capacity (W) A.T.P. U.N. Standard @30℃ (Ambient) | ||||||
|
Engine Power |
0℃ | 2,100 | 2,300 | 3,500 | 4,050 | 5,050 |
| -20℃ | 820 | 1,200 | 1,850 | 2,300 | 2,550 | |
| Cooling Capacity (W) | A.R.I. U.S. Standard @38℃ (Ambient) | |||||
|
Engine Power |
2℃ | 2,000 | 2,200 | 3,300 | 3,800 | 4,900 |
| -18℃ | 800 | 1,150 | 1,740 | 2,200 | 2,520 | |
| Evaporator blower performance | ||||||
| Flow rate (@ 0 static pressure, m3/h) | 700 | 1,500 | 1,500 | 2,500 | ||
| Velocity (m/s) | 3.0 | 3.3 | 3.3 | 3.0 | ||
| Total current consumption on the road (A) | ||||||
| 12 VDC | 30 | 36 | 36 | 44 | ||
| 24 VDC | 15 | 18 | 18 | 22 | ||
